GrimmSpeed

Manual Boost Controller

Color
Profile Avatar

Talk to an Enthusiast

Verify Fitment & Product Recommendations

M-F 9:00AM - 5:00PM

Low stock! Only 5 left

GrimmSpeed Manual Boost Controller

Fitment

Please Note: Works with any OEM or aftermarket turbo application. A boost gauge and proper tuning are required.
  • Universal

Description

GrimmSpeed Manual Boost Controller (070002): the next level of boost control

GrimmSpeed developed its Manual Boost Controller hand in hand with tuners across the country to solve legitimate problems they had with other boost controllers. the MBC lets you raise OEM boost levels quickly and efficiently through superior boost range and ultra-fine resolution (0.25 psi per click), resulting in quicker spool up, quicker response and rock-solid boost control.

This listing offers two store SKUs: grm070002 (Black) and grm070002R (Red).

Design

The GrimmSpeed MBC uses Exact Control Technology, with adjustment points that lock into place via a heavy duty stainless dual-ball detent system. An extra long travel spring gives superior range while maintaining high resolution, and an adjustment scale running the length of the controller lets you pinpoint your boost setting instead of relying on trial and error. It is CNC machined from 6061 aluminum, anodized and laser etched.

Specifications

  • 250 steps of adjustment: high-resolution control
  • 16 clicks per revolution: facilitates exact adjustment
  • Laser etched scale and labels: easy to read and repeat precise adjustments
  • Superior range without sacrificing resolution: 0-60 psi capability with ultra-fine adjustments
  • Universal mounting solution: can be rotated for multiple mounting positions
  • Precision CNC machined 6061-T6 aluminum

Before you install

Make sure you have the experience and confidence to properly tune your car, or consult a tuning professional; without a proper tune you can overboost and damage your engine. You must run a boost gauge to properly tune the Manual Boost Controller, and raising boost too high without proper tuning may destroy your engine.

Installation overview (paraphrased from GrimmSpeed's Manual Boost Controller guide, Manual 300016)

  • Attach the supplied mounting bracket to the controller with a 3mm hex wrench.
  • Choose a mounting location away from anything that could rub against it and not too close to an exhaust manifold or other hot pipe; mount with the included bolt and nut, a factory bolt or a zip tie.
  • Remove all OEM boost-controlling vacuum lines, including any restrictor pills. If the vehicle uses a boost control solenoid, recommended: leaving its electrical connector plugged in to avoid check engine lights.
  • Connect the pressure source (compressor side of the turbo, intake manifold, etc.) to the inlet at the bottom of the controller, and the wastegate actuator to the outlet on the side, using the supplied vacuum line and zip ties; use the included reducer fittings if needed.
  • Turn the knob clockwise to increase boost and counter-clockwise to decrease it. Start low and work up to your target; each click is about a quarter psi and there are 16 clicks per rotation.

Fitment

Will work with any OEM or aftermarket turbo application.

Questions & Answers

  • What vehicles does it work with? it will work with any OEM or aftermarket turbo application.
  • How fine is the adjustment? about 0.25 psi per click, 16 clicks per revolution and 250 steps of adjustment.
  • Do I need a boost gauge or tune? Yes. You must run a boost gauge to tune the controller and warns that raising boost without proper tuning can damage your engine.
  • Which colors does this listing offer? Two store SKUs: grm070002 (Black) and grm070002R (Red).
