Cometic

Cometic Be the first one to review

4AG-GE 81mm Bore .066 inch MLS Head Gasket Toyota Corolla 1985-1988 / MR2 1985-1989 | C4170-066

$12378 $137.55 Save $13.77
Earn $2.47 In JDMuscle Rewards!
Profile Avatar

Talk to an Enthusiast

Verify Fitment & Product Recommendations

M-F 9:00AM - 6:00PM

(866) 833-3536 Email Text (610) 735-6688Text
Special Order: Lead time applies. No Cancellation
Pay over time available · View all options
Katapult Affirm Klarna Shop Pay
View all options
Cometic 4AG-GE 81mm Bore .066 inch MLS Head Gasket Toyota Corolla 1985-1988 / MR2 1985-1989 | C4170-066
Be the first one to review

Fitment

Description

Comprised of multiple embossed layers of stainless steel with the outer layers utilizing a Viton rubber coating. Compressed operating thickness is 0.066". Cometic MLS (Multi-Layer Steel) Head Gaskets provide maximum sealing performance for todays high output engines and require no sealants. MLS gaskets are ideal for both aluminum heads to aluminum blocks and aluminum heads to cast iron blocks. They can withstand the shearing force created by the two materials. MLS gaskets have increased strength because they are comprised of multiple layers of stainless steel; which also creates the ability to rebound and resist corrosion. The outer layers are embossed and coated on both sides with Viton (a flour elastomer rubber based material that is heat resistant to 250 C/ 482 F). Viton is designed to meet the demands of a variety of harsh sealing environments, load conditions, and surface finishes. The center or shim layer is uncoated stainless steel, which can be varied to accommodate multiple thickness requirements.
Toyota 4A-GE/4A-GEZ .066; MLS Cylinder Head Gasket, 81mm Bore, 16-Valve.
.066" MLS Cylinder Head Gasket, 81mm Gasket Bore. Each

Air Freight Prohibited: false
Not Carb Approved: false
Ltl Freight Required: false
Prop 65: Y
Epa: N/A

Fitment:
Toyota Corolla FX16 1987
Toyota Corolla FX16 1988
Toyota Corolla FX16 GTS 1987
Toyota Corolla FX16 GTS 1988
Toyota Corolla GTS 1988
Toyota Corolla GTS 1989
Toyota Corolla GTS 1990
Toyota Corolla GTS 1991
Toyota Corolla Sport GTS 1985
Toyota Corolla Sport GTS 1986
Toyota Corolla Sport GTS 1987
Toyota MR2 GT 1985
Toyota MR2 GT 1986
Toyota MR2 GT 1987
Toyota MR2 GT 1988
Toyota MR2 GT 1989
