Types of Brakes in Vehicles & How They Work

Types of Brakes in Vehicles & How They Work

Table of Contents

−
Traditional Brakes Drum Brakes Disc Brakes Anti-Lock Brakes Advanced Types of Brakes Parking Brakes Regenerative Brakes Brake Maintenance Guidelines High-Performance Brake Parts for Subaru & Compatible Models at JDMuscle Conclusion

Curious about how your car stops when you hit the pedal? It all comes down to the types of brakes it uses. Today's vehicles rely on a mix of braking technologies—from tried-and-true drum brakes to cutting-edge regenerative systems. Learning how these systems function can shed light on maintenance needs and those dashboard alerts.

Let's dive into the most common types of brakes and their key components.

Traditional Brakes

Traditional brakes use hydraulic force. Brake fluid transmits pressure from the pedal to the wheels. The two main types are disc brakes and drum brakes. Disc brakes provide better cooling and stronger stopping power. Drum brakes are simpler and are often found on rear wheels. Anti-lock braking systems (ABS) are not separate from hydraulic brakes. They enhance them by electronically controlling pressure. This prevents wheel lock during sudden stops.

Drum Brakes

Drum brakes were introduced in 1900 as the first in-wheel brake system. Mechanical linkages, including cables and levers, initially transferred braking force. By the 1930s, hydraulic systems replaced mechanical controls to deliver better efficiency and reliability.

How Drum Brakes Work?

The operation of drum brakes depends on the brake pedal, drums, pistons, and springs. Pressing the brake pedal activates the hydraulic fluid to reach the wheel cylinder inside the drum. The generated fluid pressure directs two pistons outward to drive the brake shoes to contact the rotating drum's inner surface. The contact between the shoes and the drum causes wheel deceleration, which stops the vehicle.

Key Components of Drum Brakes

  • Brake Drum—A cylindrical component that rotates with the wheel. The brake shoes use this component as their friction point to stop the wheel rotation.
  • Brake Shoes—The brake shoes act as curved friction pads, generating contact with the drum to slow down the wheel.
  • Wheel Cylinder—The wheel cylinder is a container for pistons that push the brake shoes outward when hydraulic pressure is applied.
  • Return Spring—Return Springs act to restore brake shoe positions during the release of the brake pedal.
  • Adjuster Mechanism—The adjuster mechanism operates during operation to balance out brake shoe wear, thus stabilizing brake effectiveness.

Disc Brakes

Disc brakes were invented in the early 20th century but did not become widely used until the 1950s. Today, because of their outstanding braking capabilities, disc brakes remain the most common braking technology for modern passenger vehicles, motorbikes, and high-performance cars.

How Disc Brakes Work?

Disc brakes rely on hydraulic pressure to create friction, stopping the vehicle. When you press the brake pedal, the master cylinder sends pressurized brake fluid through the brake lines to a caliper at each wheel. Inside the caliper, pistons push the brake pads against a rotating brake rotor (or disc), which is directly connected to the wheel hub. The resulting friction slows the rotor and, in turn, the wheel.

Key Components of Disc Brakes

  • Brake Rotor (Disc)–A flat, circular metal plate attached to the wheel hub that spins with the wheel. The brake pads use the brake rotor as their friction surface.
  • Brake Pads––The brake pads consist of friction materials (organic, semi-metallic, or ceramic), which create friction against the rotor disc to stop the wheel.
  • Caliper––A caliper functions as a clamp that contains brake pads as well as pistons. It applies pressure to the pads, squeezing them against the rotor.
  • Pistons––The caliper contains small hydraulic cylinders known as pistons, which move when fluid under pressure reaches them.
  • Brake Fluid––Brake Fluid serves as a hydraulic fluid that transfers force from the master cylinder until it reaches the calipers to maintain constant braking power.

Anti-Lock Brakes

Anti-lock braking systems (ABS) represent a vital safety feature in modern vehicles. When you brake hard, ABS prevents wheel lock-up which allows you to maintain better control while reducing skidding. ABS proves most effective in slick conditions because it stops vehicles from sliding beyond control, which standard brakes would normally allow to happen.

How does ZABS Works?

The rapid control algorithm in ABS systems maintains vehicle control by adjusting brake pressure, especially during hard stops, which stops wheel lock-up. Speed sensors monitor each wheel's rotation, and if one slows too much, the ABS detects potential lock-up and activates. The control module processes this data and signals the hydraulic system to regulate braking pressure. ABS sends and reapplies brake force between 15 to 20 times per second to stop skidding while preserving braking power. The system enables effective steering control when you need to make emergency stops, which decreases their chances of losing control, particularly on slippery surfaces. Modern vehicle safety depends heavily on ABS technology because its stability-improving functions deliver significant performance enhancements and safety reduction in braking abilities.

Key Components of ABS

  • Wheel Speed Sensors—The Wheel Speed Sensors determine the speed of each wheel to send information to the ABS module.
  • ABS Control Module—The ABS Control Module processes sensor information and brake pressure.
  • Hydraulic Modulator (ABS Pump & Valves)–The Hydraulic Modulator consisting of ABS Pump and Valves adjusts fluid pressure to stop wheel lock-up.

Advanced Types of Brakes

Advanced types of brakes go beyond basic hydraulic brakes. They use electronics and smart sensors to improve safety and control. Features like ABS, EBD, and brake assist help prevent skidding and reduce stopping distances. These brakes are now standard in many modern vehicles. Let's dive into the two common types of such brakes:

Parking Brakes

A parking brake, also known as a hand brake or emergency brake, functions separately from the vehicle's hydraulic braking system. Modern parking brakes function primarily for holding cars in stationary positions while they rest at parking spots, although originally designed as a backup in case of main brake failure. The parking brake functions as an essential system that stops vehicles' unintended movements, especially on slopes.

How the Parking Brake Works?

The majority of parking brakes operate with a mechanical linkage or electronic system to immobilize the rear wheels. The handbrake lever and foot pedal activate the parking brake in cable-operated systems when they tighten a steel cable connecting to brake shoes or calipers, which push against the drum or rotor. This friction prevents wheel rotation. Modern electronic parking brakes (EPB) activate rear brakes through electric motors and provide automatic release features in addition to hill-hold assistance.

Key Components of Parking Brakes

  • Handbrake Lever or Button –The parking brake can be activated through the handbrake lever or button, which operates manually or electronically.
  • Cables and Linkages –The brake mechanism receives its force through cables and linkages that stem from the lever (in mechanical systems).
  • Brake Shoes or Calipers –The brake shoes or calipers create pressure on both the rear rotors or drums to stop wheel movement.
  • Electronic Actuators – Electronic actuators are motors that function in EPB systems to activate or deactivate the brake automatically.
  • Parking Pawl––Parking Pawl is a metal component inside automatic transmissions that locks the transmission when parked.

Regenerative Brakes

With the rise of hybrid and electric vehicles (EVs), regenerative braking systems (RBS) have become a key technology for improving energy efficiency. Unlike traditional braking, which dissipates kinetic energy as heat, regenerative brakes convert this energy into electricity, which is then stored in the vehicle's battery for later use. This process helps extend the vehicle's range and reduces overall energy consumption.

How Regenerative Brakes Work

Regenerative braking relies on the vehicle's electric motor, which acts as a generator when braking or coasting. When the driver releases the accelerator or presses the brake pedal, the motor switches modes, creating electrical resistance that slows the wheels. This resistance converts kinetic energy into electrical energy, which is fed back into the battery. The strength of regenerative braking varies by vehicle and can often be adjusted to provide more or less braking force.

Key Components of Regenerative Brakes

  • Electric Motor/Generator –Both motor operations and power generation are handled by the Electric Motor/Generator device through its dual functionality.
  • Battery Pack –The battery pack functions as a storage unit which enhances operational efficiency by maintaining converted energy.
  • Power Electronics Controller–The Power Electronics Controller regulates power movement between the battery pack and wheels alongside the motor.
  • Brake Control Unit –The Brake Control Unit coordinates regenerative braking and hydraulic braking to achieve smooth braking operations.
  • Brake Pedal and Sensors–The Brake Pedal and Sensors track braking commands to set appropriate levels of regenerative brake operation.

Brake Maintenance Guidelines

Regular brake maintenance is essential for safety, performance, and extending the lifespan of brake components. Ignoring brake wear can lead to dangerous driving conditions and costly repairs.

Signs of Brake Wear

Warning signs typically start with sound—squealing often means your pads are worn down, while grinding may suggest metal-on-metal contact, indicating rotor damage. A longer stopping distance or a brake pedal that feels soft or unresponsive could also signal performance issues. If a brake warning light appears, it may indicate low brake fluid, worn pads, or a fault in the ABS system.

Proactive Brake System Maintenance

When signs of brake wear appear, don't delay. Schedule a professional inspection to replace worn pads, check rotor condition, and address any issues. Rotors should be resurfaced or replaced if necessary to prevent further damage.

Additionally, inspect brake fluid for contamination. If the fluid is compromised, replace it with fresh, high-quality fluid to maintain braking performance. If the ABS warning light is on, have the system diagnosed to ensure optimal function and safety.

High-Performance Brake Parts for Subaru & Compatible Models at JDMuscle

Every driver deserves reliable braking performance, and JDMuscle delivers with premium brake components for Subaru vehicles and compatible platforms. While specializing in Subaru upgrades, we also cater to Toyota and Scion models sharing the same DNA, ensuring precision engineering for track days or daily drives. Our brake parts enhance stopping power, reduce fade, and provide unmatched control—ideal for enthusiasts seeking to optimize their ride.

Elevate your Subaru or compatible model's braking performance—shop JDMuscle today!

Subaru WRX brake parts

Subaru WRX STI brake parts

BRZ/FRS/GR86/ brake parts

Conclusion

Automotive brake systems are the unsung heroes of every vehicle, ensuring smooth stops and safe driving. Whether your car relies on disc, drum, or ABS brakes, regular maintenance is key to performance and longevity. Learning about how various types of brakes operate enables you to make better choices regarding repairs and upgrades. Maintain awareness of safety concerns while keeping your braking system well-maintained because this ensures both comfort and safety while driving.
